Catalogues & installation instructions

Granab has several different catalogues to best present our systems, functions and solutions.

See also separate installation instructions for the steel and wood systems.

Granab subfloor systems

System 9000N

Installation instructions – S-3000N, S-7000N, S-9000N

Installation instructions – S-8000W

Disassembly for reuse

Our systems

System 3000N

Adjustable height 30 – 180 mm, exkl. floor covering.

System 7000N

Adjustable height 50 – 420 mm, excl. floor covering.

System 8000W

Adjustable height 85 – 480 mm, excl. floor covering.

System 9000N

Adjustable height 80 – 450 mm, excl. floor covering.

Ventilated subfloor

För fukt- och/eller emissionsproblematiska bjälklag.

Sports floors

Able to accommodate natural frequencies that are as low as 10Hz.

Accessories

Assembly kit for floor drains, electricity boxes and insulation brackets etc.

Environmental certification

Granab works actively to reduce environmental impact and has certifications that confirm our commitment to sustainability. All our subfloor systems have Environmentally Product Declarations (EPD).
